PLC 1 Year Diploma training Course

Burraq Engineering Solutions is a company that provides engineering and automation solutions for a variety of industries, but I could not find information on a specific 1 year PLC diploma program that they offer. It is possible that the company offers bespoke training programs based on the specific needs of their clients, or they do not currently offer programs. I would recommend contacting Burraq Engineering Solutions directly for more information on the training they offer.

A year-long programmable logic controller (PLC) training program typically covers the basics of PLCs and their applications in various industries. The program may include courses and hands-on training in programming, troubleshooting, and maintenance of PLC systems. Courses may also include topics such as electrical circuits, industrial automation, and communication protocols used in PLC systems.

Upon completion of the program, students can work as PLC technicians or in other jobs related to industrial automation. PLCs (programmable logic controllers) are used in a wide variety of applications in industrial automation and control systems. Some common examples of PLC applications include.

PLC Diploma Outline

  • Introduction and History
  • Introduction to TIA portal and its installation
  • Programming languages stl ,fbd,ladder ,.
  • Making Simple Program in TIA
  • Add remove PLC controllers IN TIA program
  • Going online with s7-1200 plc via TIA
  • Connecting s7-1200 via Ethernet
  • Topology, network and device views
  • Upload /download program in PLCs
  • Working with different type of simulators like PLSIM and s7-plsim simulating modules
  • Integration of simulator with TIA and their offline control
  • Monitoring of plc program while online
  • Checking and setting the CPU /CONTROLLER and module properties
  • Create tags for the I/O of the CPU.
  • Create a simple network in your user program
  • Use the PLC tags in the tag table for addressing the instructions
  • Inserting new networks and deleting them
  • Adding empty box, open and close branch as well as inserting inputs
  • Program blocks and main OB
  • Bit Logic Instructions NO, NC, COIL
  • Word Logic Operations, AND, OR NOT, NAND, XOR, XNOR
  • Assignments and negative assignments
  • Set/reset coil with flip-flops
  • Timers TP, TON, TOFF and time accumulators
  • Counters UP, DOWN, UP/DOWN
  • Range and validity functions
  • Comparator Like equal to, not equal to, less than, greater than etc.(= ,> ,< ,>= ,<= )
  • Arithmetic Functions like add sub,MUL,DIV,MOD,NEG,INC,DEC,ABS ,MIN,MAX,
  • LIMIT
  • 29. MOVE Block FIELDREAD, FIELD WRITE etc.
  • Advance Functions like SWAP, CONVERT, CEIL, FLOOR
  • Special Functions
  • Plc tags and adding new tag table
  • Plc data types, int, float, double, byte etch and how to add them
  • Plc trouble shooting and maintenance
  • Watch and force table and how to add them in project
  • Introduction to analog and digital sensors
  • PT100, opt electrical, limit switches
  • Integration of sensors with plc and taking values in TIA
  • Calibrating analog sensors RTD and Thermocouple
  • Reading analog sensor value from TIA portal
  • Going online problems and theirs solutions
  • Intro to VFD and frequency drives
  • VFD parameter setting in FUJI
  • Connect VFD with PLC and control by current change
  • HMI (Human Machine Interface) Section
  • Learn to Program  WIENTEK HMI
  • Learn to design in a Utility manager
  • Creating tags in HMI in utility manager
  • Adding buttons,lamps , numeric inputs and outputs
  • Connect HMI with plc
  • Download program in HMI as well as online and offline simulations
  • HMI and plc connection problems and solutions
  • Reading  senor value at HMI
  • Controlling motors from HMI
  • Introduction to SCADA
  • Level 1 Course.
  • Jump and Label instruction in TIA Portal S7 1200/300/400 PLC
  • How to make Functions (FC) in TIA Portal
  • What is Cross Reference?
  • FCs calling in Main (OB)
  • Difference between FC and FB
  • How to make FB in TIA and How to call it
  • Force Table & Watch table
  • How to add multiple racks and connection of IM with another IM on TIA Portal
  • Uploading a PLC Program
  • RTUs concept using Provirus
  • Motor Control with VFD
  • Parameters setting of Analog IO’s in VFD from control terminals
  • Connections of Analog IO’s (0-10V or 4-20mA)
  • Forward Reverse of Motor using keypad
  • The forward reverse of Motor from an external signal
  • Controlling the Motor Acceleration and Deceleration time
  • Frequency setting range up to 120Hz
  • PLC wiring of Analog IO’s with VFD
  • Motor Speed control using VFD through PLC Motor Speed control from the thermocouple
  • Through temperature.
  • Read and Write major parameters of VFD on HMI (wiener) via MODBUS RTU using
  • RS485
  • Two VFDs/Motors Operate with their feedback (Master-Slave VFDs
  • Quick Review of Level 1  Level 2
  • WINCC FLEXIBLE RUNTIME
  • DB Block in Detail
  • FB Block in Detail
  • FC Block in Detail
  • ARRAYS
  • UDTS
  • PID
  • PLC Safety Circuit
  • Web Server
  • M
  • WINCC Explorer SCADA.
  • WINCC Explorer SCADA Graphic Designing
  • WINCC Explorer SCADA Reporting
  • WINCC Explorer SCADA connection with SQL Database by taking the value of
  • Temperature/pressure/flow/level etc.
  • Alarm Logging
  • Tag logging & Trend display
  • Gauges, sliders, motors, pipes, tanks, and other objects designed on
  • More Animations
  • Scripting
  • S7-Communication
  • PUT/GET Instruction
  • PLC to PLC Communication
  • Master Slave Communication
  • Redundant System
  • Fail-Safe PLC System
  • OPC UA
  • OPC DA
  • MQTT
  • Real-time Plant Project
  • Introduction
  • Difference between Servo and Stepper Motor
  • Overview of PLC based motion
  • HSC and PTO in S7-1200
  • How to generate PTO in S7-1200
  • Hardware wiring of Motor and Driver
  • Configuration Of Positioning Axis
  • Commissioning Of Axis
  • Programming of basic motion control functions
  • Axis Power and Axis Reset
  • Axis JOG Operation
  • Axis Homing Operation
  • Axis Move Relative Motion Control
  • MC_MoveAbsolute
  • Difference between MC_Relative and MC_MoveAbsolute
  • Axis MC_MoveVelocity
  • Axis McHale
  • What is Eliot | Iota vs. Eliot
  • Eliot Model, Architecture, Platforms, Components, Features & Benefits
  • Download Siemens TIA Portal & Eliot/MQTT Software’s
  • Download Mosquito MQTT Broker and MQTT Explorer
  • Understanding MQTT
  • MQTT Demonstration with Mosquito Broker and MQTT Explorer
  • MQTT Demonstration with Public MQTT Broker
  • TIA Portal Communication with Local MQTT Broker (Mosquito)
  • MQTT Library Overview
  • TIA Portal with Local MQTT Broker
  • Introduction to Node-Red
  • How to Install Node-Red on Windows?
  • Node-Red With PC
  • Basic Features of Node-Red
  • Basics of Node-Red
  • Inject
  • Node-Red Debug
  • Node-Red Visualization
  • Node-Red Dashboard
  • Node-Red Dashboard(Gauge)
  • Node-Red Dashboard(Graph)
  • Node-Red Dashboard
  • Data Manipulation
  • Parsing
  • TIA Portal with MQTT Broker and Nod-red

PLC 1 Year Diploma

  • Rs 150,000/-
  • Course Duration 1 Year
  • Online Session
  • On Campus Lecture + Practical
  • Video Lecture Available
  • Urdu & English
Enroll now
  • Fee: 1,50, 000
  • Duration: 1 Year
  • Timing: 9AM-11AM, 11AM-1PM, 1PM-3PM, 3PM-5PM, 5PM-7PM, 7PM-9PM
